Series 8 PTO Shaft, 1-3/8 in. 6-Spline Ends
SKU: #34195
Description
Designed for agricultural equipment requiring dependable power transfer and driveline performance. This Eurocardan® Series 8 PTO shaft is commonly used on select 15 ft. flex wing mowers and other agricultural implements requiring a splined PTO connection.
The splined tubing design helps deliver efficient torque transfer while accommodating implement movement during operation. Built for demanding agricultural applications, this PTO shaft provides reliable performance for equipment requiring durable driveline components.
Dimension
Extended Length:
53 in.
Length - Overall:
40 in.
Specification
Assembly Description:
AX8750F-SPL/MC
Brand:
Eurocardan
Description:
1-3/8 in. x 6 Spline Metal Collar Yoke
Features:
- Eurocardan® Series 8 PTO shaft assembly
- Splined implement end yoke included
- Splined tubing design for efficient power transfer
- Designed for flex wing mower applications
- Heavy-duty agricultural driveline construction
HP at 1000 RPM:
145 HP
HP at 540 RPM:
91 HP
Implement End:
1-3/8 in.
Implement End Spline Count:
6
Series:
8
Tractor End:
1-3/8 in.
Tractor End Spline Count:
6
Type:
PTO Assembly
