AX5 32-13/16 in. OL 1-3/8 in. 6 Spline

Product Documents

33029_cat_002.pdf

Description

Maintain reliable power transfer with this AX5 PTO assembly designed for medium-duty tillers and PTO generator applications. Built for dependable performance in demanding field conditions, this PTO shaft assembly provides a secure connection between the tractor and implement.

This PTO assembly features a 32-13/16 in. overall length and 1-3/8 in. 6-spline connections on both ends. Designed for AX5 series applications, it delivers dependable PTO driveline performance.

Dimension

Extended Length:

43-13/16 in.

Length - Cross to Cross:

24 in.

Length - Overall:

32-13/16 in.

Spline Count:

To Fit Shaft Size:

1-3/8 in.

Specification

Assembly Description:

AX5610A-SPL

Brand:

Eurocardan

Description:

1-3/8 in. x 6 Spline

Features:

Designed for medium-duty tiller and PTO generator applications
Splined yokes on both ends for secure attachment
AX5 series construction for dependable power transmission
Compatible with agricultural PTO driveline systems
Backed by the Agri Supply Satisfaction Guarantee

HP at 1000 RPM:

72 HP

HP at 540 RPM:

47 HP

Series:

AX5

Series Size:

Style:

Splined Yoke Both Ends

To Fit:

Medium Duty Tillers, PTO Generator

Type:

PTO Assembly

Product Documents

33029_cat_002.pdf

AX5 32-13/16 in. OL 1-3/8 in. 6 Spline
