AJ8 51 in. OL 21-Spline x 20-Spline CV PTO Shaft

Description

This AJ8 51 in. OL series 8 constant velocity PTO shaft delivers smooth and reliable power transfer from tractor to implement. Equipped with a 21-spline 80° constant velocity MPC tractor end and a 20-spline interfering bolt implement end, this shaft is rated for 91 HP at 540 RPM and 145 HP at 1,000 RPM, making it ideal for heavy-duty agricultural applications.

Featuring an 80° constant velocity u-joint for better maneuverability, this PTO shaft is built for durability and dependable performance in demanding field conditions, providing consistent angular power delivery.

Dimension

Length - Overall:

51 in.

Length - Usable:

68-27/64 in.

Weight:

66.3 lb

Specification

Brand:

Eurocardan

CV Angle:

80° MPC

Eurocardan Part #:

AJ80091#15263 / ME8920CV-SPL

Features:

80° constant velocity u-joint for smooth power delivery and better maneuverability
Rated for 91 HP at 540 RPM and 145 HP at 1,000 RPM
21-spline tractor end and 20-spline implement end for secure connections
Series 8 heavy-duty construction for demanding agricultural applications
Interfering bolt implement end for reliable shaft-to-implement fastening

HP at 1000 RPM:

145

HP at 540 RPM:

Implement End:

1-3/4 in.

Implement End Connection Type:

Interfering Bolt

Implement End Spline Count:

Series:

AJ8

Series Size:

Tractor End:

1-3/8 in.

Tractor End Spline Count:

Type:

Conversion Bushing

AJ8 51 in. OL 21-Spline x 20-Spline CV PTO Shaft
