67.3 in. Series 6 PTO Shaft with FD2 Slip Clutch, 1-3/8 in. 6-Spline Ends

SKU: #34193
Description

Designed for agricultural implements requiring dependable power transfer and driveline protection. The FD2 slip clutch helps reduce shock loads and overload conditions encountered during operation, helping protect connected driveline and gearbox components.

Suitable for a variety of agricultural equipment applications where reliable PTO performance is required. The telescoping driveline design accommodates implement movement while maintaining smooth power transmission during operation.

Dimension
Length - Overall:
67.3 in.
Specification
Assembly Description:
AX61440FD2A-HDSC
Brand:
Eurocardan
Description:
FD2 Slip Clutch - 1-3/8" x 6 Spline SPL - 1-3/8" x 6 Spline SPL QD
Features:
  • Series 6 PTO shaft assembly
  • Includes FD2 slip clutch
  • 1-3/8 in. 6-spline tractor connection
  • 1-3/8 in. 6-spline implement connection
  • Designed for agricultural implement applications
Implement End:
1-3/8 in.
Implement End Spline Count:
6
Series:
6
Tractor End:
1-3/8 in.
Tractor End Spline Count:
6
Type:
PTO Assembly
Used On:
7 ft. Pull Cutter

Product Documents

34193_cat_002.pdf
