53 in. Series 6 PTO Assembly with 1-3/8 in. 6-Spline Yokes

SKU: #33235
Description

Keep PTO-driven equipment operating efficiently with this Series 6 PTO assembly designed for dependable power transfer between the tractor and implement. Engineered for agricultural applications, it helps deliver smooth and consistent power to PTO-driven equipment while supporting reliable driveline performance.

This PTO assembly features 1-3/8 in. 6-spline yokes on both the implement and tractor ends for secure PTO driveline connections. Rated for 62 HP at 540 RPM and 98 HP at 1000 RPM, it is designed to provide dependable operation and efficient power transfer for PTO-driven agricultural equipment.

Dimension
Extended Length:
76-3/16 in.
Length - Overall:
53 in.
Spline Count:
6
Specification
Assembly Description:
AX61110F-SPL
Brand:
Eurocardan
Description:
1-3/8 in. x 6 Spline
Features:



  • Series 6 PTO assembly for agricultural driveline applications
  • 1-3/8 in. x 6-spline yokes on both tractor and implement ends
  • 53 in. closed length with 76.2 in. safe extended length
  • Rated for 62 HP at 540 RPM and 98 HP at 1000 RPM
  • Designed to provide smooth and efficient power transfer



HP at 1000 RPM:
98 HP
HP at 540 RPM:
62 HP
Series Size:
6
Type:
PTO Assembly
Used On:
7 in. Lift Cutter

Product Documents

33235_cat_002.pdf
