2-1/2 in. Bore x 5 in. Stroke x 1-1/8 in. Rod Hydraulic Cylinder

Description

Provide reliable ultra compact hydraulic actuation with this durable 2-1/2 in. bore hydraulic cylinder. Designed for demanding agricultural applications requiring balanced force output in the most compact stroke package possible.

Built with steel construction and a chrome plated 1-1/8 in. rod for corrosion resistance and long lasting service life. Features 2-1/2 in. bore with 5 in. ULTRA SHORT stroke and 15-1/4 in. compact retracted length. Ideal for quick-attach mechanisms, positioning systems, clamping applications, and equipment requiring balanced force with minimal reach.

Key Feature: ULTRA COMPACT 5 in. stroke - perfect for tight installations requiring balanced force with minimal reach.

Dimension

Diameter - Rod:

1-1/8 in.

Length - Overall:

20-1/4 in.

Length - Retracted:

15-1/4 in.

Weight:

19.9 lb

Specification

Bore:

2-1/2 in.

Brand:

Grizzly

Features:

2-1/2 in. bore x 5 in. stroke - ULTRA COMPACT design
Chrome plated 1-1/8 in. rod for corrosion resistance
Compact 15-1/4 in. retracted length
Balanced force output with minimal reach
Perfect for quick-attach and positioning applications

Finish:

Black Painted (Body), Chrome Plated (Rod) (assumed)

Stroke:

5 in.

Style:

Double Acting Tie Rod Cylinder, Ultra Compact

Type:

Hydraulic Cylinder
