1-3/8 in. x 6 Spline Series 4 LN3 Torque Limiting Pawl with Yoke

SKU: #57467
Description

This Series 4 LN3 torque limiting pawl with yoke provides dependable overload protection for PTO-driven agricultural equipment. The pawl design allows controlled disengagement when torque exceeds rated capacity, helping prevent damage to both the implement and tractor driveline components.

Built with a yoke end and 1-3/8 in. x 6 spline implement end, this torque limiter is engineered for secure engagement and consistent performance under demanding field conditions. The LN3 series is widely used across a range of farming applications where equipment protection is essential.

Dimension
Length - Overall:
6-13/16 in.
Shaft Size:
1-3/8 in.
Spline Count:
6
Weight:
5 lb
Specification
Brand:
Eurocardan
Eurocardan Part #:
1644250
Features:



  • Pawl design for controlled torque limiting and overload protection
  • Yoke end for secure tractor-side connection
  • 1-3/8 in. x 6 spline implement end for compatible equipment fit
  • Series 4 rated for light-duty agricultural implements
  • Compact design for easy installation and maintenance



Series:
4
Series Size:
4
Type:
Slip Clutch

Product Documents

57467_cat_002.pdf
