1-1/8 in. to 1-3/8 in. 6-Spline Over Run Clutch
SKU: #32439
Description
This over run clutch is engineered for PTO-driven agricultural equipment, featuring a quick release pin design for fast attachment and removal. The clutch allows the shaft to rotate in one direction while spinning freely in the opposite direction, controlling implement speed when the tractor is slowing down for safer operation.
Designed with a 1-3/8 in. 6-spline male end for tractor attachment and a 1-1/8 in. 6-spline female end for implement connection, this clutch provides secure power transfer. The quick release pin configuration ensures convenient coupling and uncoupling in the field.
Dimension
Weight:
8 lb
Specification
Brand:
Eurocardan
Eurocardan Part #:
1516113
Features:
- Quick release pin design enables fast and convenient attachment in the field
- 1-3/8 in. 6-spline male end connects securely to standard tractor PTO shafts
- 1-1/8 in. 6-spline female end attaches to compatible implement drive shafts
- Overrunning clutch mechanism controls implement speed during tractor deceleration
- Rated for tractors up to 45 HP for reliable performance in demanding applications
Implement End:
1-1/8 in. x 6 Spline Female
Max Load:
14,150 lb
Series:
RLS1
Tractor End:
1-3/8 in. x 6 Spline Male
Type:
Over Running Attachment
Used On:
Tractors Up To 45 HP
1-1/8 in. to 1-3/8 in. 6-Spline Over Run Clutch
